Sequence Step

Sequence Step
Usage: Useful in applications in which it is desirable to count by intervals other than 1.
Sequencing in Matchcode operations can occur in steps from 1 to 32,768.
Definition:
Sequencing performs like a mechanical counter by displaying positive
integers and a specific number of digits after rollovers.
For example, 000 – 3 = 997 (not –3) and 999 + 3 = 002 (not 1002).
Serial Cmd: <K228,sequence
Default: 1
Options: 1 to 32768
Note: See <K223>
As an example of Sequence Step, if Sequence Step is set to 3 and Sequential Matching
is set to Increment.
Master Symbol
003
003
003
006
006
006
7-10
step>
(Matchcode Type on page 7-5) for more information.
Decoded Symbol
001
002
003
004
005
006
Master Symbol After Decode
003
003
006
006
006
009
