Install Your Instrument
Accessory
Power Cord One of the following:
North America (Option A0)
Universal Euro (Option A1)
United Kingdom (Option A2)
Australia (Option A3)
North America 240 V (Option A4)
Switzerland (Option A5)
Japan (Option A6)
China (Option A10)
India (Option A11)
Brazil (Option A12)
No power cord or AC adapter (Option A99)

Operating Requirements

MSO70000/C, DSA70000B/C, DPO70000B/C, and DPO7000
1. Place the instrument on a cart or bench.
The instrument should rest on its bottom
or rear feet. An optional rack mounting
kit is available. Observe the following
clearance requirements and dimensions:
Top:
Left and right side:
Bottom:
Rear:
2
<4 GHz Models
0 in (0 mm)
0 in (0 mm) on right side
3 in (76 mm) on left side
0 in (0 mm) standing on feet, flip
stands down
0 in (0 mm) on rear feet
MSO70000/C, DPO/DSA70000B/C, DPO7000, and MSO/DPO5000 Series User Manual
Tektronix part number
MSO5000 DPO7000
and DPO5000 models
models
161-0348-00 161-0104-00
161-0343-00 161-0104-06
161-0344-00 161-0104-07
161-0346-00 161-0104-14
—
161-0104-08
161-0347-00 161-0167-00
161-0342-00 161-A005-00
161-0341-00 161-0306-00
161-0349-00 161-0324-00
161-xxxx-00 161-0356-00
— —
≥4 GHz Models
0 in (0 mm)
3 in (76 mm)
0 in (0 mm) standing on feet, flip
stands down
0 in (0 mm) on rear feet
≥4 GHz
models
161-0213-00
161-0209-00
161-0210-00
161-0211-01
—
161-0212-00
161-0213-00
Notice: Do
not use the
provided
power cord
for other
products.
161-0352-00
161-0325-00
161-0358-00
—
