Display a Waveform
Selecting the Waveform Interpolation
Select Display > Waveform Interpolation,
and then select one of the following:
Sin(X)/X interpolation computes record
points using a curve fit between the
actual samples acquired.
Linear interpolation computes record
points between actual acquired samples
by using a straight line fit.
92
MSO70000/C, DPO/DSA70000B/C, DPO7000, and MSO/DPO5000 Series User Manual
