Display a Waveform
Search
Runt
Window
Pattern
Transition
Timeout
State
DDR Read
DDR Write
DDR Read and Write
112
Description
Searches for positive or negative pulses that cross one amplitude threshold but fail to cross
a second threshold before crossing the first again. Search for all runt pulses or only those
with a duration >, <, =, or ≠ a user-specified time.
Searches for a signal that is entering or leaving the threshold window. Qualify the search
in terms of time by using the When Wider option, or by the logical state of other channels
using the When Logic option.
Search for a logic pattern (AND, OR, NAND, or NOR) across multiple waveforms with each
input set to either High, Low, or Don't Care. Search for when the event goes true, goes
false, or stays valid for >, <, =, or ≠ a user-specified time. Additionally, you must define one
of the inputs as a clock for synchronous (state) searches.
Search for rising and/or falling edges that are >, <, =, or ≠ a user-specified time.
Searches for no pulse in a specified time.
Searches for when all of the logic inputs to the selected logic function cause the function to
be True or False when the clock input changes state.
Searches for DDR read pulses. Requires option DDRA.
Searches for DDR write pulses. Requires option DDRA.
Searches for DDR read and write pulses. Requires option DDRA.
MSO70000/C, DPO/DSA70000B/C, DPO7000, and MSO/DPO5000 Series User Manual
