MyScope
7. Click New Tab to add a tab to your
MyScope control window. You can have
up to six tabs.
8. To rename a tab do one of the following:
Click Rename Tab.
Double-click the tab, and then type
the new name.
9. Click User Pref... to specify user
preferences that are loaded with your
MyScope control window.
10. To delete controls do one of the following:
Select a tab, and then click Delete.
The tab and all of the controls are
deleted.
Select a control, and then click
Delete. Just the selected control is
deleted.
11. Click Save, and then enter a name for
your MyScope control window, or use
the default name.
Quick Tips
To reconfigure a control, click and drag it back to the preview window. Then select or clear the check boxes to include or
remove components in the control.
To change the tab order, click and drag a tab to a new location.
To delete a control, click and drag it to the upper half of the screen (out of your MyScope control window).
