Quick Tip
You can save several different file types but you can only recall setup (*.set) files and waveform (*.wfm) files.

Saving Digital Waveforms

On MSO Series instruments, you can save digital waveforms in a .csv format file.
1. To save digital waveforms, select File >
Save or Save As > Digitals.
2. Click Digitals.
3. You can only save digital waveforms as
a .csv file in a Windows directory. To
save as a .csv file, select the location
where you want to save the waveform.
4. Type in a file name, or use the default.
5. Click Save.
