Appendix
Specifications
Table 4: Electrical and mechanical specifications
Characteristic
Input channels
Input resistance
Input capacitance
Input signal swing
Minimum
Maximum
Maximum nondest–
ructive input signal
User defined threshold range
Minimum detectable pulse width
Digital channel-to-
digital channel skew
Probe length
Table 5: Environmental specifications
Characteristic
Temperature
Operating
Nonoperating
Humidity
Operating
Nonoperating
Altitude
Operating
Nonoperating
Equipment Recycling. This product complies with the European Union's requirements according to Directive
2002/96/EC on waste electrical and electronic equipment (WEEE). For more information about recycling
options, check the Support/Service section of the Tektronix Web site (www.tektronix.com).
182
Description
16 digital
100 kΩ ±1.0%
3.0 pF
400 mV p-p
30 V p-p, ≤200 MHz (centered around the DC threshold voltage) at the
probe tip
10 V p-p, ≥200 MHz (centered around the DC threshold voltage) at the
probe tip
±42 V
±40 V
1 ns
200 ps
1.3 m (4.27 ft)
Description
0 °C to +50 °C (+32 °F to +122 °F)
–55 °C to +75 °C (–67 °F to +167 °F)
5% to 95% relative humidity
10% to 95% relative humidity
4.6 km (15,092 ft) maximum
15 km (50,000 ft) maximum
MSO70000/C, DPO/DSA70000B/C, DPO7000, and MSO/DPO5000 Series User Manual
