Install Your Instrument
Maximum input voltage, ≥4 GHz models:
50 Ω
Maximum nondestructive input voltage to
logic probes, MSO70000 Series:
CAUTION. For proper cooling, keep the bottom and sides of the instrument clear of obstructions.
MSO5000 and DPO5000
1. Place the instrument on a cart or bench.
The instrument should rest on its bottom
or rear feet. An optional rack mounting
kit is available. Observe the following
clearance requirements and dimensions:
Rear:
Left side:
2. Width:
3. Height:
4. Before operating the instrument, verify
the ambient temperature:
5. Verify the operating humidity:
6. Verify the operating altitude:
7. Maximum input voltage:
50 Ω input impedance
1 MΩ input impedance
Maximum nondestructive input voltage to
logic probes:
CAUTION. For proper cooling, keep the back and left side of the instrument clear of obstructions.
4
<1 V for <1 V/FS settings and < 5.5 V
RMS
±15 V
2 in (50.8 mm)
2 in (50.8 mm)
17.3 inches (439 mm)
9.2 inches (233 mm) including feet
10.7 inches (272 mm) including vertical handle and feet
5 °C to +50 °C (+41 °F to +131 °F)
High: 40 °C to 50 °C (104 °F to 122 °F), 10% to 60% relative humidity
Low: 0 °C to 40 °C (32 °F to 104 °F), 10% to 90% relative humidity
3,000 m (9,843 feet)
5 V , with peaks ≤±20 V (DF ≤6.25%).
RMS
300 V with peaks ≤±425 V at the BNC.
RMS
For <100 mV/div derate at 20 dB/decade above 100 kHz to 30 V
1 MHz, 10 dB/decade above 1 MHz.
For ≥100 mV/div derate at 20 dB/decade above 3 MHz to 30 V
30 MHz, 10 dB/decade above 30 MHz.
±42 V
MSO70000/C, DPO/DSA70000B/C, DPO7000, and MSO/DPO5000 Series User Manual
for ≥1 V/FS settings.
RMS
at
RMS
at
RMS
