Tektronix MSO70000/C Series User Manual page 140

Statistics
Statistics turn on automatically with
measurements. Statistics characterize the
stability of the measurement.
1. To change the statistics that are
displayed, select Measure > Statistics,
and then select Mean or All. (All includes
min, max, mean, standard deviation, and
population.)
2. To remove statistics select Off.
NOTE. Placing the cursor over a
measurement displays a higher resolution
version of the measurement.
Snapshot
To see a one-time view of all valid
measurements, select Measure >
Snapshot.
NOTE. If the setup for a measurement is
invalid, the results of that measurement is
displayed as 3 question marks.
To select between taking a snapshot of
general measurements or communications
measurements, select General or Comm.
MSO70000/C, DPO/DSA70000B/C, DPO7000, and MSO/DPO5000 Series User Manual
Analyzing Waveforms
119
