Getting Started

Table 1-1:
Model Bandwidth
MSO2024B, 200 MHz
MSO2024
MSO2022B 200 MHz
MSO2014B, 100 MHz
MSO2014
MSO2012B, 100 MHz
MSO2012
70 MHz
MSO2004B
MSO2002B 70 MHz
DPO2024B, 200 MHz
DPO2024
DPO2022B 200 MHz
DPO2014B, 100 MHz
DPO2014
100 MHz
DPO2012B,
DPO2012
DPO2004B 70 MHz
70 MHz
DPO2002B
New in the Programmer
Manual
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
This manual explains the use of commands for remotely controlling your
oscilloscope. With this information, you can write computer programs to
perform functions, such as setting the front-panel controls, taking measurements,
performing statistical calculations, and exporting data for use in other programs.
This manual describes commands for the following models:
Number
of Analog
Channels
4
2
4
2
4
2
4
2
4
2
4
2
The following major changes were made to this version of the programmer
manual (077-0738-00):
Added 6 new oscilloscope models:
MSO2002B – 70 MHz, 2 channel
MSO2004B – 70 MHz, 4 channel
MSO2022B – 200 MHz, 2 channel
DPO2002B – 70 MHz, 2 channel
DPO2004B – 70 MHz, 4 channel
Record Length,
Sample Rate all ch.
1 GS/s 1 M pts.
1 GS/s 1 M pts.
1 GS/s 1 M pts.
1 GS/s 1 M pts.
1 M pts.
1 GS/s
1 GS/s 1 M pts.
1 GS/s 1 M pts.
1 GS/s 1 M pts.
1 GS/s 1 M pts.
1 M pts.
1 GS/s
1 GS/s 1 M pts.
1 M pts.
1 GS/s
Wfm. Capture
Rate
5,000
5,000
5,000
5,000
5,000
5,000
5,000
5,000
5,000
5,000
5,000
5,000
