DESE
Group
Syntax
Related Commands
Arguments
Examples
DIAg:LOOP:OPTion
Group
Syntax
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
Sets or returns the bits in the Device Event Status Enable Register (DESER). The
DESER is the mask that determines whether events are reported to the Standard
Event Status Register (SESR), and entered into the Event Queue. For a detailed
discussion of the use of these registers, see Registers.
Status and Error
DESE <NR1>
DESE?
*CLS, *ESE, *ESR?, EVENT?, EVMsg?, *SRE,
sets the binary bits of the DESER according to this value, which ranges
<NR1>
from 1 through 255. For example, DESE 209 sets the DESER to the binary value
11010001 (that is, the most significant bit in the register is set to 1, the next most
significant bit to 1, the next bit to 0, etc.).
The power-on default for DESER is all bits set if *PSC is 1. If *PSC is 0, the
DESER maintains the previous power cycle value through the current power cycle.
NOTE.
Setting the DESER and ESER to the same value allows only those codes
to be entered into the Event Queue and summarized on the ESB bit (bit 5) of the
Status Byte Register. Use the
sets the DESER to binary 11010001, which enables the PON, URQ,
DESE 209
EXE and OPC bits.
might return
DESE? :DESE 186
value 10111010.
Sets the self-test loop option.
Calibration and Diagnostic
DIAg:LOOP:OPTion {ALWAYS|FAIL|ONFAIL|ONCE|NTIMES}
Commands Listed in Alphabetical Order
*STB?
*ESE command to set the ESER.
, showing that the DESER contains the binary
