Tektronix MSO2024B Programmer's Manual page 228

Commands Listed in Alphabetical Order
Syntax
Related Commands
Arguments
Examples
MEASUrement:REFLevel:PERCent:LOW
Group
Syntax
Related Commands
Arguments
Examples
2-212 MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
MEASUrement:REFLevel:PERCent:HIGH <NR3>
MEASUrement:REFLevel:PERCent:HIGH?
MEASUrement:REFLevel:METHod, MEASUrement:IMMed:TYPe,
MEASUrement:MEAS<x>:TYPe
is the high reference level, ranging from 0 to 100%. The default high
<NR3>
reference level is 90%.
MEASUREMENT:REFLEVEL:PERCENT:HIGH 95
to 95% of HIGH.
MEASUREMENT:REFLEVEL:PERCENT:HIGH?
:MEASUREMENT:REFLEVEL:PERCENT:HIGH 90
percentage high reference level is set to 90% of HIGH.
Sets or returns the percent (where 100% is equal to HIGH) used to calculate the
low reference level when
This command affects the results of rise and fall measurements.
NOTE.
this command affects the associated reference level parameter for all
MEASurements:IMMed and the four periodic measurements.
Measurement
MEASUrement:REFLevel:PERCent:LOW <NR3>
MEASUrement:REFLevel:PERCent:LOW?
MEASUrement:REFLevel:METHod, MEASUrement:IMMed:TYPe,
MEASUrement:MEAS<x>:TYPe
is the low reference level, ranging from 0 to 100%. The default low
<NR3>
reference level is 10%.
MEASUREMENT:REFLEVEL:PERCENT:LOW 15
15% of HIGH.
sets the high reference level
might return
MEASUrement:REFLevel:METHod
sets the high reference level to
indicating that the
is set to Percent.
