Examples
FPAnel:TURN (No Query Form)
Group
Syntax
Arguments
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
Table 2-37: FPAnel:PRESS arguments (cont.)
Argument
BMENU5
BMENU6
BMENU7
RMENU1
RMENU2
RMENU3
RMENU4
RMENU5
MAGnify
FITERVu (2000/B series only)
WFMOnly (2000/B series only)
FPANEL:PRESS AUTOSET
Simulates the action of turning a specified front-panel control knob.
When the front panel is locked, the front-panel button and multipurpose knob
operations are suspended. The
will also not work, and, they will not generate an error. You can work around
this by using the appropriate programmatic interface commands, instead of the
front-panel commands. For example, to set the trigger level to 50%, you could
use TRIGger:A SETLevel. To force a trigger, you could use TRIGger FORCe.
Miscellaneous
FPAnel:TURN <knob>,[<n>]
is the name of a rotating control.
<knob>
A comma (,) separates the control knob argument from the numeric optional
rotation value argument. In the absence of the numeric rotation value argument,
the default is 1 (clockwise). You do not need a white space between the arguments
and the comma.
represents the rotation direction and magnitude of rotation. Negative values
<n>
represent a counterclockwise knob rotation, and positive values represent a
Commands Listed in Alphabetical Order
Description
Screen bottom menu button
Screen bottom menu button
Screen right-most bottom menu button
Screen top-most side menu button
Screen side menu button
Screen side menu button
Screen side menu button
Screen bottom-most side menu button
Magnify (zoom) button (not the zoom/pan
knob)
FilterVu frequency button
Waveform data button
executes the oscilloscope Autoset function.
FPAnel:PRESS and commands
FPAnel:TURN
2-163
