Commands Listed in Alphabetical Order
Group
Syntax
Related Commands
Arguments
2-128 MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
Waveform Transfer
DATa:ENCdg
{ASCIi|FAStest|RIBinary|RPBinary|SRIbinary|SRPbinary}
DATa:ENCdg?
WFMOutpre:ENCdg, WFMOutpre:BN_Fmt,
specifies the ASCII representation for waveform data points. If ASCII is
ASCIi
the value, then :BN_Fmt and :BYT_Or are ignored.
specifies that the data be sent in the fastest possible manner consistent
FAStest
with maintaining accuracy and is interpreted with respect to the waveform
specified by DATa:SOUrce.
specifies signed integer data point representation with the most
RIBinary
significant byte transferred first.
When :BYT_Nr is 1, the range is from –128 through 127. When :BYT_Nr is 2,
the range is from –32,768 through 32,767. Center screen is 0 (zero). The upper
limit is the top of the screen and the lower limit is the bottom of the screen. This
is the default argument.
specifies the positive integer data-point representation, with the most
RPBinary
significant byte transferred first.
When :BYT_Nr is 1, the range from 0 through 255. When :BYT_Nr is 2, the
range is from 0 to 65,535. The center of the screen is 127. The upper limit is the
top of the screen and the lower limit is the bottom of the screen.
is the same as
SRIbinary
meaning that the least significant byte is transferred first. This format is useful
when transferring data to IBM compatible PCs.
is the same as
SRPbinary
meaning that the least significant byte is transferred first. This format is useful
when transferring data to PCs.
Table 2-36: DATa and WFMOutpre Parameter Settings
WFMOutpre Settings
DATa:ENCdg
Setting :ENCdg
ASCii ASC
FAStest BIN
RIBinary BIN
RPBinary BIN
SRIbinary BIN
SRPbinary BIN
WFMInpre:FILTERFreq
except that the byte order is swapped,
RIBinary
except that the byte order is swapped,
RPBinary
:BN_Fmt :BYT_Or
N/A N/A
RI MSB
RI MSB
RP MSB
RI LSB
RP LSB
:BYT_NR
1,2
1,2
1,2
1,2
1,2
1,2
