Tektronix MSO2000 Series Datasheet

Mixed Signal Oscilloscopes
MSO2000 Series, DPO2000 Series Data Sheet
Features & Benefits
Key Performance Specifications
200, 100 MHz Bandwidth Models
2 and 4 Analog Channel Models
16 Digital Channels (MSO Series)
1 GS/s Sample Rate on All Channels
1 Megapoint Record Length on All Channels
5,000 wfm/s Maximum Waveform Capture Rate
Suite of Advanced Triggers
Ease of Use Features
Wave Inspector Controls Provide Easy Navigation and Automated
®
Search of Waveform Data
FilterVu™ Variable Low-pass Filter Allows for Removal of Unwanted
Signal Noise while still Capturing High-frequency Events
29 Automated Measurements, and FFT Analysis for Simplified
Waveform Analysis
TekVPI Probe Interface Supports Active, Differential, and Current
®
Probes for Automatic Scaling and Units
7 in. (180 mm) Widescreen TFT-LCD Color Display
Small Footprint and Lightweight – Only 5.3 in. (134 mm) deep and 7 lb.
14 oz. (3.6 kg)
Connectivity
USB 2.0 Host Port on the Front Panel for Quick and Easy Data Storage
USB 2.0 Device Port on Rear Panel for Easy Connection to a PC or
Direct Printing to a PictBridge
®
Optional 10/100 Ethernet Port for Network Connection and Video Out
Port to Export the Oscilloscope Display to a Monitor or Projector
Optional Serial Triggering and Analysis
Automated Serial Triggering, Decode, and Search Options for I
CAN, LIN, and RS-232/422/485/UART
Mixed Signal Design and Analysis (MSO Series)
Automated Triggering, Decode, and Search on Parallel Buses
Multichannel Setup and Hold Triggering
Feature-rich Tools for Debugging Mixed
Signal Designs
Offering up to 200 MHz bandwidth and 1 GS/s sample rate, the
MSO/DPO2000 Mixed Signal Oscilloscope Series delivers advanced debug
features at an entry-level price. With up to 20 channels for analyzing analog
and digital signals, you can quickly find and diagnose problems in complex
designs. To capture long windows of signal activity while maintaining
fine timing resolution, the MSO/DPO2000 offers a deep record length of
1 Mpoints standard on all channels.
With Wave Inspector controls for rapid waveform navigation and
®
automated serial and parallel bus analysis, the MSO/DPO2000
Oscilloscope Series from Tektronix provides the feature-rich tools you need
to simplify and speed debug of your complex design.
-compatible Printer
C, SPI,
2
