Command Groups
2-42 MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
Table 2-31: Trigger Commands (cont.)
Command
TRIGger:A:BUS:B<x>:LIN:IDentifier:VALue
TRIGger:A:BUS:B<x>:I2C:ADDRess:MODe
TRIGger:A:BUS:B<x>:I2C:ADDRess:TYPe
TRIGger:A:BUS:B<x>:I2C:ADDRess:VALue
TRIGger:A:BUS:B<x>:I2C:CONDition
TRIGger:A:BUS:B<x>:I2C:DATa:DIRection
TRIGger:A:BUS:B<x>:I2C:DATa:SIZe
TRIGger:A:BUS:B<x>:I2C:DATa:VALue
TRIGger:A:BUS:B<x>:PARallel:VALue
TRIGger:A:BUS:B<x>:RS232C:CONDition
TRIGger:A:BUS:B<x>:RS232C:RX:DATa:SIZe
TRIGger:A:BUS:B<x>:RS232C:RX:DATa:VALue
TRIGger:A:BUS:B<x>:RS232C:TX:DATa:SIZe
TRIGger:A:BUS:B<x>:RS232C:TX:DATa:VALue
TRIGger:A:BUS:B<x>:SPI:CONDition
TRIGger:A:BUS:B<x>:SPI:DATa{:IN|:MISO}:VALue
Description
Sets or returns the binary
address string used for LIN
trigger
Sets or returns the I2C
address mode to 7 or 10-bit
Sets or returns the I2C
address type to USER
Sets or returns the binary
address string used for the
I2C trigger
Sets or returns the trigger
condition for I2C trigger
Sets or returns the I2C
trigger condition valid on a
READ, WRITE, or either
Sets or returns the length of
the data string in bytes to be
used for I2C trigger
Sets or returns the binary
data string used for I2C
triggering
Sets or returns the binary
data string to be used for a
parallel trigger
Sets or returns the condition
for a RS232C trigger
Sets or returns the length of
the data string in Bytes for a
RX RS232 Trigger
Sets or returns the binary
data string for a RX RS232
trigger
Sets or returns the length
of the data string for a TX
RS232 trigger
Sets or returns the binary
data string for a RS232
trigger if the trigger condition
involves TX
Sets or returns the trigger
condition for SPI triggering
Sets or returns the binary
data string to be used for SPI
trigger
