Syntax
Arguments
Examples
TRIGger:A:BUS:B<x>:CAN:FRAMEtype
Conditions
Group
Syntax
Arguments
Examples
TRIGger:A:BUS:B<x>:CAN{:IDentifier|:ADDRess}:MODe
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
TRIGger:A:BUS:B<x>:CAN:DATa:VALue <QString>
TRIGger:A:BUS:B<x>:CAN:DATa:VALue?
is the CAN data value in binary format. The only allowed characters
<QString>
in the
are 0, 1, and X.
QString
TRIGGER:A:BUS:B1:CAN:DATA:VALUE 1011
Sets or returns the frame type for a CAN FRAMEType trigger. Applies to bus
<x>, where x is the bus number.
This command requires a DPO2AUTO application module. This command is
only valid when the
TRIGger:A:BUS:B<x>:CAN:CONDition
Trigger
TRIGger:A:BUS:B<x>:CAN:FRAMEtype
{DATA|REMote|ERRor|OVERLoad}
TRIGger:A:BUS:B<x>:CAN:FRAMEtype?
specifies a data frame type.
DATA
specifies a remote frame type.
REMote
specifies an error frame type.
ERRor
specifies an overload frame type.
OVERLold
TRIGGER:A:BUS:B1:CAN:FRAMETYPE DATA
to DATA.
Sets or returns the CAN addressing mode for bus <x>, where x is the bus number.
Use this command to do the following:
Trigger on ID
Trigger in IDANDDATA
Commands Listed in Alphabetical Order
sets the CAN data value to 1011.
is FRAMETYPE.
sets the CAN trigger frame type
2-299
