Commands Listed in Alphabetical Order
MEASUrement:IMMed:DELay:DIRection
Group
Syntax
Related Commands
Arguments
Examples
MEASUrement:IMMed:DELay:EDGE<x>
Group
Syntax
2-188 MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
Sets or returns the starting point and direction that determines the delay "to" edge
when taking an immediate delay measurement.
NOTE.
Use the MEASUrement:IMMed:SOUrce2
"to" waveform.
Measurement
MEASUrement:IMMed:DELay:DIRection {BACKWards|FORWards}
MEASUrement:IMMed:DELay:DIRection?
MEASUrement:IMMed:SOUrce2
starts the search at the end of the waveform and looks for the last
BACKWards
rising or falling edge in the waveform.
starts the search at the beginning of the waveform and looks for the
FORWards
first rising or falling edge in the waveform.
MEASUREMENT:IMMED:DELAY:DIRECTION FORWARDS
beginning of the waveform record and looks for the first rising or falling edge.
MEASUREMENT:IMMED:DELAY:DIRECTION?
:MEASUREMENT:IMMED:DELAY:DIRECTION BACKWARDS
that searching begins at the end of the waveform record and looks for the last
rising or falling edge.
Sets or returns the slope of the edge the oscilloscope uses for the delay "from" or
"to" waveform when taking an immediate delay measurement.
Measurement
MEASUrement:IMMed:DELay:EDGE<x> {FALL|RISe}
MEASUrement:IMMed:DELay:EDGE<x>?
command to specify the delay
starts searching from the
might return
indicating
