MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
Table 3-8: Execution Warning Messages (EXE Bit 4) (cont.)
Code Message
543 Measurement warning, Low resolution
544 Measurement warning, Uncertain edge
545 Measurement warning, Invalid in minmax
546 Measurement warning, Need 3 edges
547 Measurement warning, Clipping positive/negative
548 Measurement warning, Clipping positive
549 Measurement warning, Clipping negative
Table 3-9: Execution Warning Messages (EXE Bit 4)
Code Message
540 Measurement warning
541 Measurement warning, Low signal amplitude
542 Measurement warning, Unstable histogram
543 Measurement warning, Low resolution
544 Measurement warning, Uncertain edge
545 Measurement warning, Invalid min max
546 Measurement warning, Need 3 edges
547 Measurement warning, Clipping positive/negative
548 Measurement warning, Clipping positive
549 Measurement warning, Clipping negative
The following table shows internal errors that indicate an internal fault in the
oscilloscope.
Table 3-10: Internal Warning Messages
Code Message
630
Internal warning, 50Ω overload
Status and Events
3-17
