Tektronix MSO2024B Programmer's Manual page 249

Group
Syntax
Related Commands
Arguments
Examples
REM (No Query Form)
Group
Syntax
Arguments
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
Each waveform has a vertical scale parameter. For a signal with constant
amplitude, increasing the Scale causes the waveform to be displayed smaller.
Decreasing the scale causes the waveform to be displayed larger.
Scale affects all waveforms, but affects reference and math waveforms differently
from channel waveforms:
For reference and math waveforms, this setting controls the display only,
graphically scaling these waveforms and having no affect on the acquisition
hardware.
For channel waveforms, this setting controls the vertical size of the acquisition
window as well as the display scale. The range and resolution of scale
values depends on the probe attached and any other external factors you have
specified.
Vertical
REF<x>:VERTical:SCAle <NR3>
REF<x>:VERTical:SCAle?
CH<x>:SCAle, MATH[1]:VERTical:SCAle
is the gain in user units-per-division.
<NR3>
REF2:VERTICAL:SCALE 100E-03
division.
REF2:VERTICAL:SCALE?
indicating that the current vertical scale setting for Reference 2 is
1.0000e+00
1 V per division.
Embeds a comment within programs as a means of internally documenting the
programs. The oscilloscope ignores these embedded comment lines.
Miscellaneous
REM <QString>
is a string that can contain a maximum of 80 characters.
<QString>
Commands Listed in Alphabetical Order
sets the Reference 2 scale to 100 mV per
might return
:REF2:VERTICAL:SCALE
2-233
