Command Groups
2-44 MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
Table 2-31: Trigger Commands (cont.)
Command
TRIGger:A:LOGIc:INPut:CH<x>
TRIGger:A:LOGIc:INPut:D<x>
TRIGger:A:LOGIc:INPut:CLOCk:EDGE
TRIGger:A:LOGIc:INPut:CLOCk:SOUrce
TRIGger:A:LOGIc:PATtern?
TRIGger:A:LOGIc:PATtern:DELTatime
TRIGger:A:LOGIc:PATtern:INPut:D<x>
TRIGger:A:LOGIc:PATtern:WHEn
TRIGger:A:LOGIc:PATtern:WHEn:LESSLimit
TRIGger:A:LOGIc:PATtern:WHEn:MORELimit
TRIGger:A:LOGIc:THReshold:(CH<x>|D<x>)
TRIGger:A:LOWerthreshold:CH<x>
TRIGger:A:LOWerthreshold{:EXT|:AUX}
TRIGger:A:MODe
TRIGger:A:PULse?
Description
Specifies or returns the
logic setting for the specified
channel
Sets or returns the logic
pattern for a trigger on digital
channel <x>, where x is the
channel number
Sets the polarity of the clock
channel.
Sets or returns the channel
to use as the clock source
Returns the conditions for
generating an A logic pattern
trigger
Sets or returns the pattern
trigger delta time value
Sets or returns the A logic
trigger input for the specified
digital channel <x>, where x
is the channel number.
Sets or returns the pattern
logic condition on which to
trigger the oscilloscope
Sets or returns the maximum
time that the selected pattern
may be true and still generate
an A logic pattern trigger
Sets or returns the minimum
time that the selected pattern
may be true and still generate
an A logic pattern trigger
Sets or queries the logic
trigger threshold voltage for
the specified channel
Sets or returns the lower
threshold for the channel
selected
Sets or returns the lower
threshold for the Auxiliary
input.
Sets or returns the A trigger
mode
Returns the A pulse trigger
parameters
