Status word:
The status word indicates the current operating state.
State
Switch on disabled
Ready to switch on
Switched on
Operation enabled
Quick stop active
Fault reaction active
Fault
"X" means any value.
Bit 7 "Warning" can be set at any time. It reports a device-internal warning. The
cause of the warning is evaluated by reading the warning status with parameter
Warnings
Bit 9 "Remote" is set if the operation mode is set to "Control via state machine" (
cal/Remote
Bit 10 "Target reached" is set when the specified reference value is reached.
In configurations without Motion Control (parameter
reached" refers to the reference speed from OUT-PZD2. In the special case of power
failure regulation, the bit is also set when the power failure regulation reaches the
frequency 0 Hz (see frequency inverter operating instructions).
For "Target reached", there is a hysteresis (tolerance range) which can be set via the
parameter
Bit 11 "Internal limit value active" indicates that an internal limit is active. This
may be the current limit, the torque limit or the overvoltage control. All functions will
result in the reference value being left or not reached.
Bit 15 "Warning 2" signals a critical operating state which will result in a fault switch-
off of the frequency inverter within a short time. This bit is set if there is a delayed
warning relating to the motor temperature, heat sink/inside temperature, Ixt monitor-
ing or mains phase failure.
10/13
Bit 6
Switch on
disabled
1
0
0
0
0
0
0
270.
412 = 1) and controller release is turned on.
549 see frequency inverter Operating Instructions).
Max. control deviation
ACU
Modbus/TCP
Status word
Bit 5 Bit 3 Bit 2
Quick Fault Operation
stop (Low enabled
active)
0 0
X
1 0 0
1 0 0
1 0 1
0 0 1
X 1 1
1 0
X
Configuration
Bit 1 Bit 0
Switched Ready to
on switch on
0 0
0 1
1 1
1 1
1 1
1 1
0 0
Lo-
30 ≠ x40) "Target
71
