14.4

Application warning messages

When the highest bit of the warning message is set, an "Application warning message" is present.
The application warning messages are bit-encoded as per the following pattern via parameter
274. Parameter
cation warnings
the control panel and the VPlus PC control software.
Use parameter
Application warnings
Bit no.
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
For details on the warnings, refer to the frequency inverter Operating Instructions and
the "Positioning" application manual.
The Warning Bit 6 "Absolute encoder" can be read out via Parameter 1274 in VPlus or
1273 via field bus. The Absolute encoder warnings are described in detail in the Ex-
tension manual EM-ABS-01.
10/13
Application warnings
274 in order to read the warning messages via Field Bus.
Application warning messages
Warning
code
0x0001 BELT
0x0002 SW-LIM CW
0x0004 SW-LIM CCW
0x0008 HW-LIM CW
0x0010 HW-LIM CCW
0x0020 CONT
0x0040 ENC
0x0080 User 1
0x0100 User 2
0x0200 (reserved)
0x0400 (reserved)
0x0800 (reserved)
0x1000 (reserved)
0x2000 (reserved)
0x4000 (reserved)
0x8000 (reserved)
ACU
Modbus/TCP
273 indicates the warnings as plain text in
Description
- V-belt
– SW limit switch clockwise
– SW limit switch anticlockwise
– HW limit switch clockwise
– HW limit switch anticlockwise
– contouring error
– Warning Absolute encoder
– User Warning 1
– User Warning 2
Appli-
127
