14.3

Warning messages

The different control methods and the hardware of the frequency inverter include functions for con-
tinuous monitoring of the application. In addition to the messages documented in the frequency in-
verter user manual, further warning messages are activated by the Field Bus module. The bit-coded
warning reports are issued via parameter
270 is provided for read-out via a PLC, Parameter
ter
Warnings
mation, including a brief description in VPlus and the control panel.
Bit no.
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
The meanings of the individual warnings are described in detail in the frequency in-
verter Operating Instructions.
126
270 according to the following pattern: Parame-
Warnings
Warning messages
Warning
code
0x0001 Warning Ixt
0x0002 Warning short-time Ixt
0x0004 Warning long-time Ixt
0x0008 Warning heat sink temperature Tk
0x0010 Warning inside temperature Ti
0x0020 Warning Limit
0x0040 Warning Init
0x0080 Motor temperature warning
0x0100 Warning mains failure
0x0200 Warning motor circuit breaker
0x0400 Warning Fmax
0x0800 Warning analog input MFI1A
0x1000 Warning analog input A2
0x2000 Warning System Bus
0x4000 Warning Udc
0x8000 Warning
Application warning status
ACU
Modbus/TCP
269 provides the infor-
Warnings
Description
367
10/13
