7.2.9

Exception condition codes

The frequency inverter generates the following exception condition codes:
Code Modbus name
1 INVALID FUNCTION
2 INVALID DATA AD-
DRESS
3 INVALID DATA VALUE
4 SLAVE DEVICE ERROR
Error number Meaning
0 No error
1 Non-permissible parameter value.
2 Non-permissible dataset
3 Parameter not readable (write-only)
4 Parameter not writable (read-only)
5 EEPROM read error
6 EEPROM write error
7 EEPROM checksum error
8 Parameter cannot be written while the drive is running
9 Values of data sets are different
10 Wrong parameter type
11 Unknown parameter
12 Checksum error in received telegram
13 Syntax error in received telegram
14 Data type of parameter does not match the number of bytes in the telegram
15 Unknown error
When parameter
VABusSST Error Register
10/13
Reason of generation by frequency inverter
• Function code unknown
• Sub-function code unknown (diagnosis function)
• Wrong number of registers (must always be 0x01)
• Unknown parameter or data type of parameter unknown
• Block check error
• Number of bytes in too small or too high
• Certain fields not set to typical values
• Unsuccessful reading or writing of parameters
The cause of the error can be analyzed by reading parameter
VABusSST Error Register
VABusSST Error Register
11 is read, it is deleted automatically at the same time.
ACU
Modbus/TCP
11.
