6.2.2 TCP/IP address & Subnet settings
For proper identification, each frequency inverter is assigned a TCP/IP address which must be unique
in the system.
6.2.2.1 Network without DHCP server:
The address is set via parameter
be entered properly for the local network.
Parameters
No. Description
1432 IP Address
1433 Netmask
6.2.2.2 Network with DHCP server:
When a DHCP server is used, manual network configuration is not required. Set
to "1-Enabled" if you wish to use the DHCP function.
DHCP Option 1436
0 - Disabled
1 - Enabled
6.2.3

Modbus/TCP Timeout settings

The communication can be monitored: If communication fails, no data or faulty data will be transmit-
ted. The Modbus/TCP Timeout feature will identify this state.
The timeout feature monitors communication for the time defined by parameter
1439. The set value represents the time in milliseconds where correct data transfer must
Timeout
take place.
If no data is transferred correctly within this time, the frequency inverter will signal the fault F2735
Modbus/TCP Timeout.
Parameters
No. Description
1439 Modbus/TCP Timeout
When the parameter is set to 0 (factory setting), the monitoring function is off.
24
1432. In addition, the subnet mask
IP-Address
Min.
0.0.0.0 255.255.255.255
0.0.0.0 255.255.255.255
Module must be configured manually, no DHCP server is used.
(Factory setting).
The settings are made by a DHCP server.
Min.
0 ms
ACU
Modbus/TCP
-Netmask
Settings
Max. Factory setting
172.22.1.25
255.255.255.0
DHCP Option
Function
Settings
Max. Factory setting
60000 ms 0 ms
1433 must
1436
Modbus/TCP
