Recycling

Symbol Meaning
Recycling, to avoid waste, collect all materials for
reuse
2.6.6

Grounding symbol

Symbol Meaning
Ground connection
2.6.7

ESD symbol

Symbol Meaning
ESD: Electrostatic Discharge (can damage com-
ponents and assemblies)
2.6.8

Information signs

Symbol Meaning
Tips and information making using the frequency
inverter easier.
2.6.9

Font style in documentation

Example Font style
1234
bold
italic, Font
Parameter
Times New Roman
P.1234 bold
Q.1234
bold
2.7

Directives and guidelines to be adhered to by the operator

The operator must follow the following directives and regulations:
Ensure that the applicable workplace-related accident prevention regulations as well as other ap-

plicable national regulation are accessible to the staff.
An authorized person must ensure, before using the frequency inverter, that the device is used in

compliance with its designated use and that all safety requirements are met.
Additionally, comply with the applicable laws, regulations and directives of the country in which

the frequency inverter is used.
Any additional guidelines and directives that may be required additionally shall be defined by the op-
erator of the machine/plant considering the operating environment.
2.8

Operator's general plant documentation

• In addition to the user manual, the operator should issue separate internal operating instructions
for the frequency inverter. The user manual of the frequency inverter must be included in the user
manual of the whole plant.
