6.1.1

Installation instructions

The Modbus/TCP module is connected to the PLC or other devices using standard CAT cables and
RJ45 connectors:
Ethernet standard:
Cable type:
6.2

Setup

By default, the parameters of the CM-Modbus/TCP and CM-Modbus/TCP-2P communication modules
are set up as follows:
Parameters
No. Description
388
Bus Error Behaviour
1432
IP-Address
1433
Netmask
1434
Gateway
1435
DNS Server
1436
DHCP Option
1437
IP Command
1440
Email Function
1441
Email Text (Body)
1439
Modbus/TCP Timeout
The parameter settings must be adapted to the actual application.
6.2.1

TCP/IP configuration

For the configuration of the IP address, Netmask, etc., refer to the CM-VABus/TCP user manual. For
details refer to the CM-VABus/TCP user manual, Chapter "TCP/IP configuration".
10/13
IEEE 802.3, 100Base-TX (fast Ethernet)
S/FTP (cable with braided shield, (ISO/IEC 11801 or EN 50173, Straight
Through or Cross Over)
ACU
Modbus/TCP
Settings
Factory setting
1
172.22.1.25
255.255.255.0
0.0.0.0
0.0.0.0
0
-
0
-
0
23
