14.5

Error messages

The error code stored following a fault comprises the error group FXX (high-byte,
hexadecimal) and the code YY (low-byte, hexadecimal).
Key
Motion F04 04
Control
F14 42
Interface 43
44
45
46
47
48
51
52
53
60
61
62
63
64
65
66
70
71
72
73
74
75
76
F15 xx
70
71
72
73
Ethernet
F27 14
The current error can be read via parameter
Parameter
panel and the VPlus PC control software.
In addition to the error messages mentioned, there are other error messages speci-
fied in the Operating Instructions. The errors of the Motion Control Interface (F14xx,
F15xx) are described in detail in the "Positioning" application manual.
128
Communication error
Control deviation position controller
Pos. SW limit switch
Neg. SW limit switch
Pos. SW limit sw. < Neg. SW limit sw.
Pos. and Neg. HW-Lim Switch Simultaneously
Limit Switch Incorrect Wired
Pos. HW Limit Switch
Neg. HW Limit Switch
Switch: Pos. Dir. Blocked
Switch: Neg. Dir. Blocked
System bus-Synchronization not activated
Pos. HW Limit Sw.: Non-permissible signal source
Pos. HW Limit Sw.: Input deactivated by PWM /FF input
Pos. HW Limit Sw.: Input deactivated of index controller
Pos. HW Limit Sw.: wrong mode for MFI1
Pos. HW Limit Sw.: Input deactivated by encoder 1
Pos. HW Limit Sw.: Input deactivated by encoder 2
Pos. HW Limit Sw.: wrong mode for EM-S1IOD
Neg. HW Limit Sw.: Non-permissible signal source
Neg. HW Limit Sw.: Input deactivated by PWM /FF input
Neg. HW Limit Sw.: Input deactivated of index controller
Neg. HW Limit Sw.: wrong mode for MFI1
Neg. HW Limit Sw.: Input deactivated by encoder 1
Neg. HW Limit Sw.: Input deactivated by encoder 2
Neg. HW Limit Sw.: wrong mode for EM-S1IOD
User-Defined Error in Motion Block xx (1 £ xx £ 32)
No Homing Done
Homing Encoder-Mode w.o. Z-Impulse
Both Directions Locked
No Touch Probe Signal Detected
Communication loss to PLC
259 indicates the current error as plain text in the control
Current error
ACU
Modbus/TCP
Meaning
260.
Current error
10/13
