13 Parameter List

The parameter list is sorted numerically. For better overview, the parameters are marked
with pictograms:
The parameter is available in the four data sets.
The parameter value is set by the SET-UP routine
This parameter cannot be written when the frequency inverter is in operation.
13.1 Actual values (Menu "Actual")
No.
11 VABusSST-Error-Register
228 Internal reference frequency
240 Actual speed
249 Active dataset
260 Current error
270 Warnings
274 Warning application
282 Bus reference frequency
283 Ramp reference frequency
411 Status word
1107 Act. Speed
1108 Actual Position
1109 Act. Contouring Error
1129 Act. Master Speed
1246 Actual Motion Block
1249 Motion Block to Resume
1431 Module Info
Parameters
accessible via Field Bus. They cannot be addressed via the VPlus control software or the
control unit.
10/13
Actual value parameter
Description
RS485/RS232
Actual values of frequency inverter
Bus control
Actual values of Motion Control Interface (MCI)
VABus/TCP
260,
Current error Warnings
ACU
Modbus/TCP
Unit Indication range
- 0 ... 15
Hz -1000,00 ... 1000.00
-1
min -60000 ... 60000
- 0 ... 4
- 0 ... 0xFFFF
- 0 ... 0xFFFF
- 0 ... 0xFFFF
Hz -999.99 ... 999.99
Hz -999.99 ... 999.99
- 0 ... 0xFFFF
31 31
u/s -2 ... 2 -1
-2147483647 ...
u
2147483647
-2147483647 ...
u
2147483647
31 31
u/s -2 ... 2 -1
1)
- -10 , -3 ... 32
- -1 ... 32
String
270 and
Application warnings
Chapter
7.2.9
11.3.3
11.3
11
14.5
14.3
14.4
12
12
11.2
12.1
11.4.5
VABus/TCP
manual
274 are only
