Error messages

The various control methods and the hardware of the frequency inverter includes
functions which continuously monitor the application. As a supplement to the messag-
es documented in these operating instructions, the following failure keys are activated
by the EM-ABS-01 extension module.
F04
F14
03/12
Error messages and repair
00 Motor temperature too high or temperature evaluation connection defec-
tive. Check cables and connections.
80 Error during EM module initialization.
Initialization of extension module failed. Check if extension module is
plugged in correctly.
81 EM-module communication failure.
Communication between extension module and frequency inverter is faul-
ty. Check EMC.
82 General EM module error.
Error on extension module.
One of the following errors F1483 ... F1493 has occurred.
83 EM-ABS-01: No ext. 24V.
Via parameter
Power supply
power supply was selected, but there is no external voltage. Connect ex-
ternal power source or change operation mode.
84 EM-ABS-01: Ext. 24V voltage level too low.
The voltage level of the external power supply is too low or the external
power supply is overloaded. Check the voltage level of the external power
supply.
85 EM-ABS-01: Int. 24V voltage level too low.
The internal power supply to the encoder provided by the frequency inver-
ter is overloaded. Check the connections at the control terminals.
86 EM-ABS-01: No sense line.
− Via parameter
Power supply
measuring line was selected, but no sense line is connected. Connect
sense measuring line or select another operation mode.
− Sense measuring line defective or broken. Check cables and connec-
tions.
87 EM-ABS-01: A/B track missing.
A/B track not found. Connect A/B track.
A/B track cable broken. Check cables and connections.
Check set
Division marks
In some cases, you may have to reset the device if the error occurs direct-
ly after connection of mains supply.
88 EM-ABS-01: Fault correction A/B track.
Error during evaluation of A/B track. Required measuring accuracy not
reached. The offset and amplification error correction for the A/B track
has reached its maximum.
EM-ABS-01 for ACU
1186, an operation mode using an external
1186, an operation mode using a sense
1183.
