Recycling

Symbol Meaning
Recycling, to avoid waste, collect all materials for
reuse
2.6.6

Grounding symbol

Symbol Meaning
Ground connection
2.6.7

ESD symbol

Symbol Meaning
ESD: Components and assemblies sensitive to
electrostatic energy
2.6.8

Information signs

Symbol Meaning
Tips and information making using the frequency
inverter easier.
2.6.9

Font style in documentation

Example Font style
1234 bold
italic, Font Times
Parameter
New Roman
P.1234
bold
Q.1234
bold
14
Use
Representation of parameter numbers
Representation of parameter names
Representation of parameter numbers without name, e.g. in
formulas
Representation of source numbers
ACU
Spindle Applications 11/13
