Configuring Source Route to Transparent Bridging
Enabling SRTB for a Group
The
command allows you to display configured groups and the status of SRTB (either
or
), and to enable or disable SRTB for a specific group. To display groups and the
status of SRTB:
1. Enter the
A screen similar to the following is displayed:
2. To enable SRTB for a group, enter the
where
example, to enable SRTB for Group 1, you would enter the following:
3. Once you have entered the command, a screen similar to the following is displayed:
Enter
to enable SRTB for this group.
4. Once you have enabled SRTB, the following prompt appears:
Create a ring ID for the Ethernet segment assigned to this group. This number can be in
decimal or hexadecimal form, but it must be unique. For example, if you have a token
ring segment with a ring ID of 2, then you could not assign the number 2 to an Ethernet
ring ID.
5. Once you have assigned an Ethernet token ID, the following prompt appears:
Choose to employ Spanning Tree Explorer (STE) frames or All Route Explorer (ARE)
frames by entering
there is no record in the RIF table. ARE frames ignore port blocks set up by spanning tree
to avoid loops, while STE frames adhere to the spanning tree configuration. The default is
.
Page 17-44
command at the system prompt, as shown
is the number of the group for which SRTB is to be enabled. For
or
. Explorer frames are sent to learn MAC addresses when
command at the system prompt, as shown:
