WSX-FT1/E1-SC Technical Specifications
Number of ports
Connector Types
Standards Supported
Frame Formats
Line Coding
Data Rates Supported
Compression
Facility Datalink Protocol
MAC Addresses Supported
Connections Supported
Cable Supported
Cable Distance
Power Consumption
1 or 2 T1 or E1 ports
1 or 2 Universal Serial ports
T1/E1: RJ-48C
Serial: High-density, 26-pin shielded
RFCs 1406, 1213, 1659
T1: Superframe, Extended Superframe, Unframed
E1: E1, E1-CRC, E1-MF, E1-CRC-MF, Unframed
T1: B8ZS or AMI
E1: HDB3 or AMI
T1: 1.544 Mbps
E1: 2.048 Mbps
Serial: 56, 64, 128, 256, 384, 512, 768, 1024, 1536,
1544, 2048 Kbps
Hardware-based using STAC 9705
ANSI T1.403 and AT&T 54016
4,096
Physical Data Terminal Equipment (DTE) or
Data Communication Equipment (DCE)
Serial Ports
DTE or DCE of the following types:
R2-232, V.35, X.21, RS-530, RS-449
T1/E1 (short haul): 200 meters
T1/E1 (long haul): 1829 meters
WSX-FT1/E1-SC-1W without an HRE-X: 5.75 amps
WSX-FT1/E1-SC-1W with an HRE-X: 7.25 amps
WSX-FT1/E1-SC-2W without an HRE-X: 7.25 amps
WSX-FT1/E1-SC-2W with an HRE-X: 8.75 amps
