Omni Switch/Router Chassis and Power Supplies

OmniS/R-5

The OmniS/R-5 chassis has five slots for an
Slots are numbered from 1 to 5 starting with the topmost slot. Slots for two power supplies
are located at the bottom of the chassis.
The entire chassis can be wall-mounted or rack-mounted. You can view all cabling, power
supplies, module interfaces, and
The OmniS/R-5 uses the
module in Slot 1. You can install a switching module in Slot 2 (if an
or an . When dual-redundant
MPX
and the other in Slot 2. Slots 3 through 5 are reserved for switching modules.
Page 1-10
o Warning o
If you have an OmniS/R-5 with a single power supply,
do not remove the cover on the empty power supply
slot. In addition, if you have any empty switching
module slots in an OmniS/R-5, you must cover them
with blank panels (available from Alcatel) to prevent
your chassis from overheating.
Covering empty slots forces air to flow directly over the
power supplies, thereby cooling them. If the power
supplies are not properly cooled, they will overheat
and shut down.
s at the front of the chassis.
LED
The OmniS/R-5
. Slot 1 is reserved for the
MPX
are installed, one of them must be installed in Slot 1
MPXs
and switching modules (see figure below).
MPX
; you cannot install a switching
MPX
is installed in Slot 1)
MPX
