ESX-K-100C-32W Technical Specifications
Number of ports
Connector Type
Standards Supported
Data Rate
Maximum Frame Size
MAC Addresses Supported
Connections Supported
Cable Supported
Maximum Cable Distance
Current Draw
Auto-Sensing 10/100 Ethernet Modules
32
RJ-45
IEEE 802.3; IAB RFCs 826, 894
10 or 100 Mbps (full or half duplex)
1,518 bytes
ESX-K-100C-32W: 1,024
ESX-K-100C-32W4: 4,096
10BaseT hub or device
100BaseTx hub or device
10BaseT
Unshielded twisted-pair (UTP)
100BaseTx
Unshielded twisted-pair:
Category 5, EIA/TIA 568
Shielded twisted-pair
Category 5, 100 ohm
100 m
10.25 amps without an HRE-X
11.75 amps with an HRE-X
Page 3-17
