14. Continue to pivot the disk drive bracket handle against the chassis, applying mild
pressure until the drive disconnects.
15. Slide the drive out of the chassis and place it on the electrostatic discharge mat.
16. Secure the drive bay cover over the drive bays (
You must install the drive bay cover over the drive bays to ensure proper airflow in
the system.
7.1.2

Installing a Hard Disk Drive

1. Attach the antistatic wrist strap.
Refer to
2. Remove the drive bay cover (
3. Hold the bracket handle on the disk drive open.
4. Slide the replacement disk drive into the drive slot.
5. Gently push the drive until the locking handle engages.
6. Close the locking handle completely, using gentle downward pressure.
7. Replace the drive bay cover.
8. Log in to the server and, as root, activate the replacement hard disk drive:
# cfgadm -c configure ap_id
where ap_id is the attachment-point ID for the hard disk drive that you just installed.
For example, to activate the upper hard disk drive (HDD 0), as root, enter:
# cfgadm -c configure c0::dsk/c0t0d0
7-8 Netra CT Server Service Manual • January 2004
Section 1.2, "Attaching the Antistatic Wrist Strap" on page
FIGURE 7-1
).
FIGURE 7-2
).
1-2.
