Figure 10-3 Locating The Power Distribution Unit Leds On The System Status Panel - Sun Microsystems Netra CT Service Manual

FIGURE 10-3
FIGURE 10-4
A power distribution unit may have failed if a power supply is inserted, the locking
mechanism is in the locked (
PDU is OFF.
Note – Verify the DC input power cable is plugged into the PDU before replacing
the PDU. If the DC input power cable is unplugged, plug it in and check the PDU
LEDs on the system status panel again.
10-6 Netra CT Server Service Manual • January 2004
Locating the Power Distribution Unit LEDs on the System Status Panel (Netra
CT 810 Server)
Locating the Power Distribution Unit LEDs on the System Status Panel (Netra
CT 410 Server)
Power distribution unit LEDs
Power distribution unit LEDs
) position, and the green Power LED ( ) for the
