Replacing A Fan Tray - Sun Microsystems Netra CT Service Manual

8.5.2

Replacing a Fan Tray

1. Insert the fan tray into the system:
If you are installing a fan tray into a Netra CT 810 server, press the fan tray into
I
place until the fan tray clicks into place (
If you are installing a fan tray into a Netra CT 410 server, make sure the handle
I
on the fan tray is on the right, and press the fan tray handle to lock the fan tray
into place (
2. Install the system status panel on the system.
Refer to
instructions.
3. Verify that the fan tray LEDs are lit properly.
FIGURE 8-15
FIGURE 8-16
A fan tray is functioning properly if the amber Fault LED (
panel is OFF and the green Power LED (
).
FIGURE 8-20
Section 8.1.2, "Replacing the System Status Panel" on page 8-4
shows the locations of the fan tray LEDs on the Netra CT 810 server and
shows the locations of the fan tray LEDs on the Netra CT 410 server.
Chapter 8 Removing and Replacing Hot-Swappable Subassemblies
).
FIGURE 8-19
) on the system status
) is ON.
for those
8-21
