Connecting a PC Laptop to an Alarm or Alarm Rear Transition Card
TABLE B-6
Server
Type COM 1 Port on Netra CT Server
Netra CT • Front-access model: RJ-45 on the alarm
810 server
card. See Section A.4, "Alarm Card,
6U Single-Wide" on page
• Rear-access model: DB-9 male on the
alarm rear transition card. See
Section A.6, "Alarm Rear Transition
Card" on page
• Front-access model: RJ-45 on the alarm
Netra CT
410 server
card. See Section A.4, "Alarm Card,
6U Single-Wide" on page A-14
Section A.5, "Alarm Card, 3U Double-
Wide" on page
• Rear-access model: DB-9 male on the
alarm rear transition card. See
Section A.6, "Alarm Rear Transition
Card" on page
2. Set the following connection parameters:
No parity
I
9600 baud
I
1 stop bit
I
8 bit data
I
B-6 Netra CT Server Service Manual • January 2004
A-14.
A-22.
or
A-18.
A-22.
Adapter Cable
• Front-access DB-9 female-to-
model: DB-9 female
RJ-45-to- null modem
DB-9 male
• Rear-access
model:
Not needed
• Front-access DB-9 female-to-
model: DB-9 female
RJ-45-to- null modem
DB-9 male
• Rear-access
model:
Not needed
Serial Port
on PC
Adapter Laptop
Not DB-9
needed. male
Not DB-9
needed. male
