Note – Do not remove a power supply unit if the amber Okay to Remove LED (
on the system status panel is OFF; that means that the power supply unit is not hot-
swappable, and your server will be powered off if you remove that power supply
unit.
FIGURE 8-12
4. Push the purple locking mechanism up into the unlocked (
FIGURE 8-13
a Netra CT 810 server. The two LEDs on the power supply unit should go off. In
addition, after several seconds, the amber Okay to Remove LED (
status panel for the remaining power supply unit in the Netra CT 810 server should
go to OFF. This tells you that the remaining power supply unit is no longer hot-
swappable as long as you have the first power supply unit disabled.
8-14 Netra CT Server Service Manual • January 2004
Power supply unit LEDs
Locating the Power Supply Unit LEDs on the System Status Panel (Netra CT
810 Server)
shows the location of the locking mechanism for a power supply unit in
)
) position.
) on the system
