TABLE 6-2
Amber
Green Okay to
Power Remove
LED state LED state Meaning
Off Off The slot is empty or the
system thinks that the slot is
empty because the system
didn't detect the card when
it was inserted.
Blinking Off The card is coming up.
On Off The card is up and running.
Off On The card is powered off.
Blinking On The card is powered on, but
it is offline for some reason
(for example, a fault was
detected on the card).
On On The card is powered on and
is in use, but a fault has been
detected on the card.
6-24 Netra CT Server Service Manual • January 2004
CompactPCI Board Slot LED States and Meanings on the System Status Panel
Action
If there is a card installed in this slot, then one of the
following components is faulty:
• the card installed in the slot
• the alarm card
• the system controller board
Remove and replace the failed component to clear this
state.
Wait several seconds for the card to completely come
up. Do not remove the card in this state.
No action necessary. Do not remove the card in this
state.
It is okay to remove the card in this state.
Wait several seconds to see if the green Power LED
stops blinking. If it does not stop blinking after several
seconds, enter cfgadm and verify that the card is in the
unconfigured and disconnected state, then perform the
necessary action, depending on the card:
• Alarm card—It is okay to remove the alarm card in
this state.
• All other cards—Power off the slot through the
alarm card software, then it is okay to remove the
card.
Deactivate the card using one of the following
methods:
• Use the cfgadm -f -c unconfigure command to
deactivate the card. Note that in some cases, this
may cause the system to panic, depending on the
nature of the card hardware or software.
• Halt the system and power off the slot through the
alarm card software.
The green Power LED will then give status
information:
• If the green Power LED goes off, then it is okay to
remove the card.
• If the green Power LED remains on, then you must
halt the system and power off the slot through the
alarm card software.
