FIGURE 6-23
810 server and
in a Netra CT 410 server.
Front of
chassis
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
Slot 7
Slot 8
FIGURE 6-23
Front of
chassis
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
FIGURE 6-24
4. Unplug any cables attached to the alarm rear transition card, if necessary.
6-44
Netra CT Server Service Manual • January 2004
shows the slot available for the alarm rear transition card in a Netra CT
FIGURE 6-24
Hard disk drives
Host CPU card
I/O card
I/O card
I/O card
I/O card
I/O card
I/O card
Alarm card
Supported Location for the Alarm Rear Transition Card in a Netra CT 810
Server (Top View)
6U or 3U alarm card
I/O card
Host CPU card
I/O card
I/O card
Supported Location for the Alarm Rear Transition Card in a Netra CT 410
Server (Top View)
shows the slot available for the alarm rear transition card
Hard disk drives
Host CPU RTC
I/O RTC
I/O RTC
I/O RTC
I/O RTC
I/O RTC
I/O RTC
Alarm RTC
Alarm RTC
I/O RTC
Host CPU RTC
I/O RTC
I/O RTC
Midplane
Rear of
chassis
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
Slot 7
Slot 8
Midplane
Rear of
chassis
