3. Remove the satellite CPU or I/O card from the front of the Netra CT server.
Refer to Section 6.1.2.1, "Removing a Main Card" on page 6-8
then return here.
Caution – Do not proceed with these instructions unless you have removed the
satellite CPU or I/O card from the front of the server using those instructions. If the
I/O slot holding the satellite CPU or I/O card is set to basic hot swap, you will have
to manually deactivate the I/O slot that holds the satellite CPU or I/O card.
Removing the rear transition card without going through those procedures might
panic or hang your system.
4. After you have removed the satellite CPU or I/O card from the front of the Netra
CT server, go to the rear of the server and locate the rear transition card.
shows the slots available for the rear transition cards in a Netra CT 810
FIGURE 6-21
server and
FIGURE 6-22
Netra CT 410 server.
5. Unplug any cables attached to the rear transition card, if necessary.
6. Using a No. 2 Phillips screwdriver, loosen the two captive screws inside the rear
transition card's ejection levers, one on top and one on the bottom (
7. Unlock the ejection levers.
8. Press outward on the two ejection levers on the card to unseat the card from the
card cage.
9. Carefully slide the rear transition card out of the slot and place it on the
electrostatic discharge mat.
10. Perform any additional card-specific hardware procedures, if necessary.
For example, you may want to remove the PIM(s) from a faulty satellite CPU or I/O
card and install it on the replacement card later on. Refer to the documentation that
you received with your card for more information.
11. Secure blank filler panels over the empty I/O slots, if necessary.
If you are not going to replace the cards right away, you must install blank filler
panels over the openings to ensure proper airflow in the system. The slot filler
panels are secured to the card cage using two screws, one at the top of the filler
panel, the other at the bottom.
shows the slots available for the rear transition cards in a
Chapter 6 Removing and Replacing Hot-Swappable Cards
for those instructions,
).
FIGURE 6-4
6-41
