10
C H A P T E R
Removing and Replacing Cold-
Swappable Subassemblies
This chapter specifies procedures for the initial installation, removal, and
replacement of cold-swappable Netra CT server subassemblies. It is divided into the
following sections:
Section 10.1, "Hard Disk Drive" on page 10-1
I
Section 10.2, "Power Distribution Unit (DC Models Only)" on page 10-4
I
Section 10.3, "AC Power Entry Unit (AC Models Only)" on page 10-11
I
Section 10.4, "Front-Access DC Cable (Front-Access DC Models Only)" on
I
page 10-13
Section 10.5, "Power Supply Unit" on page 10-16
I
Consult the Netra CT Server Safety and Compliance Manual for safety information prior
to performing the procedures in this chapter.
Note – Read
10.1

Hard Disk Drive

This section tells you how to remove and replace an internal hard disk drive. An
internal hard disk drive is one that fits in a bay within a server. It is distinguished
from an external hard disk drive, which is attached by a cable that connects to an
I/O card in the server.
Though the Netra CT 410 server has one disk bay and the Netra CT 810 server has
two, the procedures for removal and replacement of a disk are the same for both
types of servers.
Chapter 3 before performing the procedures in this chapter.
10-1
