6.3.3

Alarm Rear Transition Card

The alarm rear transition card for the Netra CT 810 server consists of two separate
cards:
The alarm card
I
The alarm rear transition card
I
When one of the two cards fails, you may not be able to determine which of the two
cards has failed. Because of this, you may want to replace both the alarm card and
the alarm rear transition card.
The alarm card is installed from the front of the Netra CT server. It is the same alarm
card that is used in the front-access model of the Netra CT server.
The alarm rear transition card extends the ports on the alarm card installed at the
front of the server to the alarm rear transition card installed at the rear of the server.
The alarm card must be installed in the front of the server in order for the alarm rear
transition card to work.
If you are removing and replacing faulty cards in the server, first to go
I
Section 6.3.3.1, "Removing an Alarm Rear Transition Card" on page
to
If you are installing new cards in the server, go to
I
Alarm Rear Transition Card" on page
6.3.3.1 Removing an Alarm Rear Transition Card
1. Attach the antistatic wrist strap.
Refer to
2. Remove the alarm card from the front of the Netra CT server.
Refer to
here.
Caution – Do not proceed with these instructions unless you have removed the
alarm card from the front of the server using those instructions. If the I/O slot
holding the alarm card is set to basic hot swap, you will have to manually deactivate
the I/O slot that holds the alarm card, and removing the alarm rear transition card
without going through those procedures might panic or hang your system.
3. After you have removed the alarm card from the front of the Netra CT server, go
to the rear of the server and locate the alarm rear transition card.
Section 6.3.3.2, "Installing an Alarm Rear Transition Card" on page
Section 1.2, "Attaching the Antistatic Wrist Strap" on page
"Removing a Main Card" on page 6-8
6-45.
for those instructions, then return
Chapter 6 Removing and Replacing Hot-Swappable Cards
6-43, then go
6-45.
Section 6.3.3.2, "Installing an
1-2.
6-43
