6.2.1

Removing a Host CPU Front Transition Card

1. Attach the antistatic wrist strap.
Refer to
2. Go to the front of the system and remove the host CPU card, if you have not done
so already.
Refer to
CPU card, then return here.
3. Locate the host CPU front transition card.
FIGURE 6-13
410 server.
Ejection lever
FIGURE 6-13
4. Disconnect any cables attached to the host CPU front transition card.
5. Using a No. 2 Phillips screwdriver, loosen the captive screw inside the card's
ejection lever.
6. Flip up on the ejector lever to unseat the card from the card cage (
7. Slide the card out of the slot and place it on the electrostatic discharge mat.
Section 1.2, "Attaching the Antistatic Wrist Strap" on page
Section 6.1.2.1, "Removing a Main Card" on page 6-8
shows the location of the host CPU front transition card in a Netra CT
AB OR
T
RE
SE T
AL AR
M/ US
ER
RE
AD
Y
H D
ET HE
RN
ET
H D
D 1
micro syste
ms
CO M
HO TS W
AP
HO
T
SW
AP
HO
T
SW
AP
Host CPU Front Transition Card Location in a Netra CT 410 Server
Chapter 6 Removing and Replacing Hot-Swappable Cards
D 0
AB OR
T
H D
D 0
RE
SE T
AL AR
M/ US
ER
RE
AD
Y
ET HE
RN
ET
micro
syste ms
CO
M
HO
TS W
AP
HO
T
SW
AP
1-2.
to remove the host
).
FIGURE 6-13
6-29
