B.3

To Use a PC Laptop

1. Get the appropriate cable(s) and adapter(s) and make the necessary connections.
You may need one or more cables and adapters in order to connect a PC laptop to
the server. The cables and adapters you need varies, depending on the model server
you have and the card that you are connecting to.
If you are connecting a PC laptop to a CPU or CPU transition card, use the
I
information in
If you are connecting a PC laptop to an alarm card or alarm rear transition card, use
I
the information in
Connecting a PC Laptop to a CPU or CPU Transition Card
TABLE B-5
Server
Type TTY A Port on Netra CT Server
Netra • Rear-access model: DB-9 male
CT 810
on the CPU rear transition
server
card. See Section A.3, "CPU
Rear Transition Card" on
page A-10.
• Front-access model: DIN-8
Netra
CT 410
female on the CPU card. See
server
Section A.1, "CPU Card" on
page A-2.
• Rear-access model: DB-9 male
on the CPU rear transition
card. See Section A.3, "CPU
Rear Transition Card" on
page A-10.
to make the necessary connections.
TABLE B-5
to make the necessary connections.
TABLE B-6
Adapter Cable
Not DB-9 female-to-DB-9
needed. female null modem
Not • Front-access model:
needed. DIN-8 male-to-
DB-25 male
• Rear-access model:
DB-9 female-to-
DB-9 female null
modem
Appendix B Connecting a Terminal Console to the Server
Adapter
Not needed.
• Front-access model:
DB-25 female-to-
DB-9 female
• Rear-access model:
Adapter not
needed.
Serial
Port on
PC
Laptop
DB-9
male
DB-9
male
B-5
