Sun Microsystems Netra CT Service Manual page 107

18. Determine if you are removing a card from a front-access or rear-access model
server.
If you are removing a card from a front-access model of the Netra CT server, you
I
do not have to remove any additional hardware (unless you are removing the
host CPU front transition card from the Netra CT 410 server; in that case, go to
Section 6.2, "Front-Transition Card" on page
If you are removing a card from a rear-access model of the Netra CT server, you
I
must also remove the rear transition card. Go to
Alarm Rear Transition Card" on page
6.1.2.2 Inserting a Main Card
Caution – When inserting a number of cards to different slots in the system, insert
the cards one at a time and wait until each card is fully configured in the system. If
you insert multiple cards in rapid succession and at the same time, you may panic or
hang the system.
Note – If you are installing a Netra CP2140 host CPU board into a Netra CT server,
do not change the default SMC module switch settings on the SW0501 switches. The
Netra CT server supports high availability hot swap; however, because the alarm
card controls the high availability on the Netra CT server, the settings on the
SW0501 switches on the Netra CP2140 host CPU card should actually be set in the
default, non-high availability settings. Refer to the Netra CT Server Product Overview for
more information.
1. Attach the antistatic wrist strap.
Refer to
2. Locate the card slot where you will be installing the card.
FIGURE 6-1
shows the locations of these cards in the diskfull Netra CT 410 server, and
shows the locations of these cards in the diskless Netra CT 410 server.
3. Determine if you are installing a card in the front-access model or the rear-access
model of the Netra CT server.
If you are installing a card in the front-access model of the Netra CT server, go to
I
Step
If you are installing a card in the rear-access model of the Netra CT server, install
I
the rear transition card first using the instructions in
Alarm Rear Transition Card" on page
instructions, return here.
Section 1.2, "Attaching the Antistatic Wrist Strap" on page
shows the locations of these cards in the Netra CT 810 server.
4.
Chapter 6 Removing and Replacing Hot-Swappable Cards
6-28).
Section 6.3.3.1, "Removing an
6-43.
Section 6.3.3.2, "Installing an
6-45. Once you've completed those
1-2.
FIGURE 6-2
FIGURE 6-3
6-17
