4. Remove the slot filler panel, if necessary.
The slot filler panel is secured to the card cage using two screws, one at the top of
the filler panel, the other at the bottom. Store the slot filler panel in a safe place; you
may have to use it again if you have to remove a card for an extended period of
time.
5. Get the replacement card from the ship kit.
6. If you are installing a new alarm card, remove the blue protective film from the
front of the alarm card, if necessary.
Caution – You must remove the blue protective film from the front of card before
installing it into the server. Failure to do so may keep the metal springfingers on the
side of the alarm card from making contact with the metal panels on the server.
7. Perform any card-specific hardware procedures, if necessary.
For example, if you removed a PMC from a satellite CPU or I/O card, then you will
want to install the PMC into the replacement satellite CPU or I/O card at this time.
Refer to the documentation that you received with your satellite CPU or I/O card for
more information.
8. Verify that the ejection levers on the card are unlocked.
You will not be able to install the card properly if the ejection levers are locked.
9. Keeping the card vertical, slide the card into the slot between the two guides.
The cuts in the handle of the card must align with the square cutouts in the slot.
When the card is completely seated in the card cage, the two ejection levers should
flip inward, and the notches in the ejection levers should fit smoothly in the
rectangular cutouts in the bottom and top plates.
